MACHINES
VTL(CNC)
DESCRIPTION
Job diameter
Tools: 12 Tools ATC
Height: 900 mm
Accuracy: 10 microns
MAKE:TOSHIBA TUE 15
CNC Horizontal Machining Center(HMC)
DESCRIPTION
Table size from 1000mm to 630mm
X axis : 1800 mm
Y axis : 1400 mm
Z axis : 1600 mm
Spindle Nose BT-50
MAKE:MAZAK-FH-10800
CNC Turning Center
DESCRIPTION
Maximum Turning phi - 800mm
Between Centre Length: Maximum-1800mm
12 tools ATC
MAKE:CNC
CNC Vertical Machining Center(VMC)
DESCRIPTION
Table size Maximum Length -2400mm
Table size Maximum Width -800mm
X-axis from 2500mm
Y-axis from 800mm
Z-axis from 800mm
MAKE:HAAS-VF5
Tread Milling Machine
DESCRIPTION
Maximum Length -2000mm
Milling Length 1200mm
Maximum hi - 300mm
Maximum Module - 12
MAKE:WWW-HECKERT
CNC Gear Hobbing Machine
DESCRIPTION
Max Dia: 600mm
Max Module: 10
Face Width: 400mm
MAKE:PREMIER CNC
Gear Shaping Machine
DESCRIPTION
Maximum Internal- phi 1700mm
Maximum External- phi 1800mm
Maximum Module - 12
Maximum FW -200mm
MAKE:TOS-DHO
Thread Grinding Machine
DESCRIPTION
Maximum Length 700mm
Maximum phi 200mm
Grinding length - 450mm
Maximum Module -8
MAKE:REISHAUER
Internal Grinding
DESCRIPTION
Maximum OD- phi 800mm
Maximum ID phi- 600mm
Maximum Stroke Length - 400mm
MAKE:WOTAN/WMW/HELIX
Internal Cylindrical Grinding
DESCRIPTION
Maximum OD- phi 300mm
Maximum ID phi- 120mm
Depth - 120mm
MAKE:SRB MAKE
CNC Gear Grinding Machine
DESCRIPTION
Max. Dia 400mm
Max. Module 10M
Class of accuracy: DIN 5
MAKE:HOFLER/REISHAUER
CNC Gear Grinding Machine Rapid-1000
(Extended 1500)
DESCRIPTION
External Grinding:
Max Tip circle Dia (with tail stock) 1000mm
Max Tip circle Dia (without tail stock) 1500mm
Max Module 16M
Class of accuracy: DIN5
Internal Grinding(R2):
Max OD - 1000mm
Min Tip Circle Dia 250mm
Max Profile Height 35mm
Face Width 250mm
Grinding wheel 250mm
Grinding Wheel (width) 40mm
MAKE:HOFLER Rapid-1000
Rapid-1000(Extended 1500)
DESCRIPTION
Maximum External Ø - 1500mm
Maximum Internal Ø - 1200mm
Maximum Module - 30
MAKE:HOFLER
Gear Tester PSFU-1200
DESCRIPTION
Maximum External ø-1200mm
Maximum Module-30
Accuracy-DIN 3
Repeatablity-1micron
MAKE:KLINGELNBERG
Gear Tester(CNC ) P-100
DESCRIPTION
Maximum External ø-1000mm
Maximum Module-20
Accuracy-DIN 3
Repeatablity-0.5 micron
MAKE:KLINGELNBERG
CNC Horizontal Machining Center
DESCRIPTION
Table Size 1000mm
X- Axis 1750mm
Y- Axis 1300mm
Z- Axis 1000mm
Spindle Nose - BT-50
MAKE:HMT - 1000 ( 60 Tool ATC)
CNC Wire Cutting EDM
DESCRIPTION
Table Size 350 x 250 mm
Max Ø 300 mm
Z-axis 300 mm
MAKE:CONCORD (China) DK7725
CNC Wire Cutting EDM
DESCRIPTION
Table Size 500 x 400 mm
Max Ø 400 mm
Z-axis 500 mm
MAKE:CONCORD (China)DK7740
CNC Wire Cutting EDM
DESCRIPTION
Table Size 500 x 400 mm
Max Ø 400 mm
Z-axis 500 mm
MAKE:CONCORD (China)DK7740
CNC Horizontal Machining Center
DESCRIPTION
Table Size 600mm
X- Axis 800mm
Y- Axis 700mm
Z- Axis 800mm
Spindle Nose - BT-50
MAKE:HMT - 600 ( 60 Tool ATC)
CNC Horizontal Machining Center
DESCRIPTION
Table Size 1000mm
X- Axis 1700mm
Y- Axis 1400mm
Z- Axis 1600mm
Spindle Nose - BT-50
MAKE:Mazak FH-10800 ( 80 Tool ATC)
Conventional Lathe
DESCRIPTION
Maximum Turning Ø 1000mm
Between Center 4000mm
Steady rest holding Ø 350mm
MAKE:WMW
CNC Turning Center
DESCRIPTION
Maximum Turning ø 700mm
Between centre 1800mm
Tool: 12 tools
MAKE:HMT SBC - 55
CNC Turning Center
DESCRIPTION
Maximum Turning ø 540mm
Between centre 1200mm
Tool: 12 tools
MAKE:HMT SBC - 35
Shot Blasting & Shot Peening Machine
DESCRIPTION
Airless Shot Blasting Machine Model THT-120-90/90-65/2W-1
MAKE:Surface Finishing Equipment CoJODHPUR, Rajasthan
Gear Hobbing Machine
DESCRIPTION
Maximum Ø 1200mm
maximum module 30
Maximum FW 1000mm
MAKE:Premier Pfauter LC-1202 Liebherr HMT-H-200
Gear Hobbing Machine
DESCRIPTION
Maximum Ø 2000mm
maximum module 16
Maximum FW 500mm
MAKE:Premier Pfauter LC-1202 Liebherr HMT-H-200
Gear Shaping Machine
DESCRIPTION
Maximum Internal Ø 1500mm
Maximum External Ø 1200mm
maximum module 10
Maximum FW 200mm
MAKE:Russian, Fellow, Kikai,Lorenz,TOS-OHO-50 A, OHO-50, OH-6,HMT-Meshmatic
Gear Shaving Machine
DESCRIPTION
Maximum Ø 320mm
Maximum Length 300 mm
maximum stroke Length 150mm
Maximum Module 4
MAKE:Russian Shaver,National Broach (RED RING)
Broaching Machine
DESCRIPTION
Horizontal :16T x1600mm Length
Vertical : 25T x 2000 mm Length
MAKE:HMT Frost
Thread Milling Machine
DESCRIPTION
Maximum length 2000 mm
Milling Length 1200 mm
maximum Ø 300 mm
Maximum Module 12
MAKE:HILLE Germany WMW Germany
Thread Grinding Machine
DESCRIPTION
Maximum length 700 mm
Maximum Ø 200 mm
Grinding Length 450 mm
Maximum Module 8
MAKE:REISHAUER
CNC Shaping machine
DESCRIPTION
Maximum Module 10
Maximum Internal Ø600mm
Maximum External Ø500mm
Maximum F W 180mm
MAKE:YKCM5150D
