INSPECTION EQUIPMENTS
CNC - CMM
DESCRIPTION
X axis 760 mm
Y axis 1010 mm
Z axis 610 mm
Accuracy 0.005L/200mm
Repeatability 5-6 microns
MAKE:CMM ACCURATE
CNC- CMM
DESCRIPTION
X-axis from 1200mm
Y-axis from 1500mm
Z-axis from 1000mm
Repeatability- 2 micron
MAKE:CMM GMT
Gear Tester (CNC) P-100
DESCRIPTION
ME Dia 1000mm
Max Module 20
Accuracy DIN 3
Repeatability 5 microns
MAKE:KLINGELNBERG CNC P-100
Gear Tester PSFU-1200
DESCRIPTION
ME Dia 1200mm
Max Module 30
Accuracy DIN 3
Repeatability 1 microns
MAKE:KLINGELNBERG PSFU 1200
Digital Height Master
DESCRIPTION
Maximum Dia phi 900mm
Maximum Length 1200mm
Repeatability - 1 Micron
MAKE:TRIMOS
Crack Detecting Instrument(NDT)
DESCRIPTION
To detect surface cracks on Material without destroying the part.
MAKE:Magnafield controls
Crack Detecting Instrument(NDT)
DESCRIPTION
NDT - To detect surface cracks on gear
after gear grinding operation
without destroying the part
MAKE:Magnaflux
Ultra Sonic Testing machine
DESCRIPTION
To detect crack in raw material below 2mm & above.
Can be used to Inspect at different stage of process
MAKE:Ultrasonic Tester
Ultimate Tensile Testing Machine
DESCRIPTION
Maximum Capacity 400KN
Measuring Range 0-400KN
Accuracy +/- 1.0%KN
Load Resolution-0.02
MAKE:Ultrasonic Tensile Testing MACHINE (FIE)
